EnPSXBW wireless battery pistol style tightening wrench
•Features
high-precision controlRedundant monitoringMulti stage tighteningwireless connectionIndependent system integrationIntegrated display screenShock absorption and protectionstatus displayModular maintenanceQuick Change DesignPower Saving ModeHigh lifespan transmissionNon contact switchCompact design
Product Description
- High-precision control: Integrated torque sensor and angle detection system to ensure extremely high process consistency for every fastening operation.
- Redundant monitoring: Uses motor current loss as a redundant reference for torque to ensure the reliability of safety-related or quality-critical connections.
- Multi-stage fastening: Supports non-stop multi-step controlled fastening processes, optimizing assembly operations through precise control strategies.
- Wireless connectivity: Built-in WLAN module supporting standard authentication protocols, enabling direct integration into existing production networks.
- Independent system integration: Supports protocols such as XML, LSA, and Open Protocol, allowing direct connection to production systems as a standalone tool without an external controller.
- Integrated display screen: Display built into the battery connection block to show real-time torque, angle, IO/NIO status, error messages, and system diagnostic data.
- Vibration damping and protection: Features smooth acceleration and deceleration ramps and soft cut-off function to effectively reduce physical impact on operators.
- Status indication: Equipped with fully visible LED status indicators to clearly display rotation direction and fastening results.
- Modular maintenance: Measuring sensors and electronic modules can be independently removed and replaced, reducing long-term maintenance costs.
- Quick-replacement design: Equipped with externally replaceable fuses to further shorten downtime in case of equipment failure.
- Energy-saving mode: Features a dedicated wake-up button to quickly restore the tool from Sleep mode, balancing energy efficiency and high productivity.
- Long-life drivetrain: Adopts new gear ring technology to significantly improve spindle accuracy and extend tool service life in harsh environments.
- Non-contact switch: Uses a completely non-contact trigger switch design to greatly improve the durability of electronic switch components. Compact design: The body length is reduced by 15 mm to 17 mm compared with previous models, enabling operation in narrower industrial spaces.
