EnKCX electric servo ultra compact offset tightening shaft
•Features
Compact structure and efficient operationIndustrial grade wear-resistant and long-lasting useIntelligent chips and automatic parameter recognitionPrecise monitoring and process reliabilityExcellent performance and technical specifications
Product Description
- Compact structure and efficient operation: adopting ultra small and lightweight design, specially developed for single/multi-channel tightening needs in narrow spaces; Equipped with a high dynamic motor, the work efficiency is increased by up to 35%, significantly reducing production costs, and widely applicable for robot, activity sunroof, and airbag assembly.
- Industrial grade wear resistance and long-term use: designed for harsh industrial application environments, the built-in motor and gear unit have extremely high service life; The sturdy and durable structure ensures the stability of the tool during long-term operation and effectively reduces maintenance costs in the later stage.
- Intelligent chip and automatic parameter recognition: The built-in data chip stores all key factory data, and can be connected to the AMT controller to achieve automatic parameter reading without manual setting; At the same time, the chip records the number of tightening cycles in real-time, supporting the development of precise preventive maintenance plans.
- Precise monitoring and process reliability: using torque sensors and linear Hall sensors to work together, achieving precise control of torque tolerance ± 7% and angle accuracy ± 3 °; By multiple monitoring of torque, angle, and current consumption, ensure that every tightened connection meets safety and quality standards.
- Excellent performance and technical specifications: Provides a maximum torque output of 48 Nm and a high speed of 1481 rpm, with support for starting at 0 rpm; Equipped with brushless drive motors and reaction force torque sensors, advanced sensor technology provides comprehensive safety assurance for assembly processes.
